How to select the melt pump?

CC refers to the rotational displacement of the melt pump, that is, the displacement of the melt pump per revolution; The displacement of melt pumps is usually selected according to the production capacity of customers. Each series has different output of melt pumps. For example, zb-h-100cc melt pump is applicable to the melt with high temperature requirements, and the output is 100cc (rotational displacement) * 40 RPM = 4000 ml / min. The rotation speed of the melt pump is adjustable. For example, when the melt pump rotates 20 times, the output of the 100cc melt pump is 100cc (rotational displacement) * 20 RPM = 2000 ml / min. Therefore, the output per hour of zb-h-100cc melt pump is 100cc * 20 revolutions * 60 minutes = 120L / h at 20 revolutions, and 100cc * 40 * 60 minutes = 240L / h at 40 revolutions. If the output is within 120l-240l per hour, choose 100cc melt pump.

chemical melt pump

The selection of melt pump is to confirm which series of melt pump is selected according to the viscosity, temperature and specific working conditions of the material. For example, the standard zb-b series melt pump is widely applicable to PP, PS, pet, PC and other materials; Zb-h high temperature and high pressure melt pump can be selected for those with high material and temperature resistance requirements; Or for special materials such as PVC, you can choose PVC special melt pump.

hot melt gear pump

Zhengzhou Batte provides melt pumps matched with various types of extruders. At present, all kinds of rubber and plastic extrusion production lines in China, such as: pipe extrusion production line, wood plastic extrusion production line, composite pipe complete extrusion production line, granulation production line, etc., need to be equipped with melt pumps to improve the output of the complete production line and the quality of products. info@battemachinery.com
